IgG4-related Orbital Inflammation
IgG4-related disease (IgG4-RD) is a systemic condition in which fibroinflammatory lesions rich in IgG4+ plasma cells can be present in single or multiple organs of the body. When the disease manifests in the eye or orbit, it is referred to as IgG4-related ophthalmic disease (IgG4-ROD), which most commonly causes painless swelling of the lacrimal gland(s). Other commonly affected parts of the eye and orbit include the extraocular muscles, orbital fat, infraorbital nerve, eyelid, and the nasolacrimal duct system. Diagnostic criteria combine physical examination, imaging, and histopathologic findings detailing the number of IgG4+ cells/HPF and the ratio of IgG4+ to IgG+ cells/HPF. Imaging can aid in diagnosis and tissue biopsy is necessary to exclude other conditions on the differential such as malignancy. Medical treatments with corticosteroids and/or immunosuppressants such as rituximab are the mainstay of therapy. Observation, radiotherapy, and surgical resection have had variable results.
- 1 Disease Entity
- 2 Diagnosis
- 3 Management
IgG4-Related Orbital Inflammation Otherwise known as: Orbital IgG4-related disease, IgG4-related orbital pseudotumor, IgG4-related ophthalmic disease (IgG4-ROD).
IgG4-RD was first presented in 2001 in a Japanese study of patients with autoimmune pancreatitis (AIP) who were found to have elevated serum IgG4 levels. Subsequently, many AIP patients were found to have fibroinflammatory lesions in other areas and organs of the bodies including the biliary tree, retroperitoneum, salivary glands, orbit, lymph nodes, kidneys, lungs, meninges, aorta, breast, prostate, thyroid, pericardium, and skin. The orbit was the first extra-pancreatic site of IgG4-RD reported in the literature.
IgG4-RD is a systemic inflammatory disorder in which fibrosing lesions may be found in various areas and organs of the body. IgG4-RD is the umbrella term for systemic disease, while IgG4-ROD is the more specific term for manifestations in the eye and orbit.
The incidence of IgG4-ROD has been reported between 5-20% among inflammatory orbital lesions. In Japan, the incidence of AIP secondary to IgG4-RD is reported to be 0.28-1.08 cases per 100,00 people. Since IgG4-RD may go undiagnosed and the above figure does not take into account extra-pancreatic sites of involvement, it is thought that the true incidence is higher. Incidence has not yet been reported in the US.
Frequency of IgG4-ROD Location
The lacrimal gland is the most commonly involved site in IgG4-ROD (62-88%). Other common sites include the trigeminal nerve (9.5-39%), extraocular muscles (19-25%), orbital fat (28.6-40%), eyelid (12%), and the nasolacrimal duct system (1.5-9.5%). Less commonly, IgG4-ROD may affect the sclera.
IgG4-RD, particularly AIP, tends to occur more often in older males compared to females (2.8-7.5:1). However, for IgG4-ROD, disease tends to occur in a younger group of patients (55 years versus 58-69 years), affect men and women more equally (1.3:1), and be associated with salivary gland lesions and a higher serum IgG4 level. IgG4-ROD has also been found to be associated with asthma and allergic rhinitis. IgG4-ROD patients may have an increased risk of non-Hodgkin lymphoma compared to patients with the pancreatic form of IgG4-RD.
There are 3 major pathologic features of IgG4-RD:
- Dense lymphoplasmacytic infiltrate
- Focally storiform fibrosis
- Obliterative phlebitis
The diagnosis of IgG4-RD can usually be made when 2 of the 3 major features are present on pathology (most commonly the combination of a dense lymphoplasmacytic infiltrate and focally storiform fibrosis). Minor pathologic features include non-obliterative phlebitis and mild to moderate tissue eosinophilia. In IgG4-ROD, there are typically T-lymphocytes, and storiform fibrosis may not be present in lacrimal gland involvement. When infraorbital nerve involvement is present, nerve fascicles tend to remain intact on pathology, as the disease involves the epineurium without fibrosis. Other potential findings include germinal centers and obliterative arteritis (more common in the lung). The presence of histiocytes, granulomas, giant cells, or necrobiosis is unusual and suggests alternate diagnosis.
On immunohistochemistry, there should be >10 IgG4+ plasma cells/hpf (varies by organ system) and a ratio of IgG4+ plasma cells:IgG+ plasma cells >40%. In lacrimal gland disease, >100 IgG4+ cells/hpf are needed to make the diagnosis.
The etiology and pathogenesis of IgG4-ROD is currently unknown. Generally, pathogenesis is thought to revolve around humoral and cell-mediated immunity. Given that rituximab, which targets peripheral CD20+ naïve and memory B-cells, is an effective treatment for IgG4-ROD, one idea for pathogenesis is the indirect or direct effect of B-cell depletion on T-cell behavior.
In addition, certain subsets of patients with IgG4-RD are thought to have allergic mechanisms causing their disease. Some IgG4-RD patients with AIP are found to have symptoms of atopy, a history of allergy, or peripheral blood eosinophilia (PBE), as well as elevated serum IgE, implicating T-helper type 2 cells (Th2) in the pathogenesis. IgG4-ROD has previously been found to be associated with a significant increase in the expression of Th2 cytokines. Th2 cells induce the production of cytokines IL-4, IL-5, and IL-13, which cause PBE and elevation of both serum IgG4 and IgE.
Other theories of pathogenesis involve exposure to antigens in the upper aerodigestive tract and mucosal surfaces. Lacrimal glands affected by IgG4-ROD have previously been found to demonstrate somatic hypermutation, suggesting local immune response to antigen.
Patients with IgG4-ROD most commonly have lacrimal gland involvement (dacryoadenitis) and tend to present with painless, unilateral or bilateral periorbital and/or eyelid swelling, erythema, and proptosis. Previously, bilateral lacrimal gland enlargement associated with salivary gland enlargement was referred to as Mikulicz’s disease, before the discovery of IgG4-RD as a unique clinical entity. Compared to patients with traditional idiopathic orbital inflammation, IgG4-ROD patients experience less pain and tend to have more bilateral disease.
Involvement of extraocular muscles (EOMs) or orbital soft tissue is also associated with proptosis. EOM involvement may cause pain, diplopia, restrictive strabismus (less common than in Graves orbitopathy), and enlargement of the infraorbital canal/bone. The inferior rectus muscle is the most commonly affected EOM, followed by the superior rectus-levator complex, lateral rectus, medial rectus, inferior oblique, and superior oblique muscles.
Less commonly, compressive optic neuropathy secondary to mass effect from inflammatory lesions may result in visual loss, afferent pupillary defect (APD), or visual field defects. Mass effect can particularly occur in patients with infraorbital nerve (ION) enlargement, which is defined as the ION being greater in size than the optic nerve. ION enlargement is significantly correlated with elevated serum IgG4 levels. Sensory loss is extremely rare. Other less common manifestations are frontal nerve and perioptic nerve lesions.
Involvement of the nasolacrimal duct system can cause epiphora. Very rarely, patients may present with destruction of bony structures comprising the orbit. In patients with extra-orbital involvement, systemic lymphadenopathy may be present with the most common sites being the salivary glands (especially the parotid and submandibular glands). In rare cases of IgG4-ROD causing scleritis, patients may present with conjunctival and scleral injection with blurred vision.
Imaging can aid in diagnosis, especially in cases of orbital soft tissue or EOM involvement, which are better appreciated on orbital imaging. Imaging techniques include CT or MRI of the orbits, and FDG-PET/CT scan. MRI will demonstrate isointensity on T1-weighted lesions, hypointensity on T2-weighted lesions, and homogenous gadolinium enhancing lesions. FDG-PET scan can be used for systemic evaluation in IgG4-RD, as it can locate distant and/or clinically silent lesions. There are currently no guidelines on how often FDG-PET/CT should be performed.
Umehara et al. developed the following comprehensive diagnostic criteria for systemic IgG4-RD in 2012:
- Clinical examination shows characteristic diffuse/localized swelling or masses in single or multiple organs.
- Hematologic examination shows elevated serum IgG4 concentrations (≥135 mg/dl).
- Histopathologic examination shows: (i) Marked lymphocyte and plasmacyte infiltration and fibrosis (ii) Infiltration of IgG4+ plasma cells: ratio of IgG4+ to IgG+ cells >40% and >10 IgG4+ plasma cells/HPF.
Definite IgG4-RD occurs when criteria 1, 2 and 3 are all present. Probable disease occurs when criteria 1 and 3 are present. Possible disease occurs when criteria 1 and 2 are present.
If diagnosis cannot be reached using the above comprehensive criteria, organ-specific diagnostic criteria may be used as well.
For ophthalmic and orbital disease, Goto et al. developed the following IgG4-ROD diagnostic criteria in 2015:
- Imaging studies show enlargement of the lacrimal gland, trigeminal nerve, or extraocular muscle as well as masses, enlargement, or hypertrophic lesions in various ophthalmic tissues.
- Histopathologic examination shows marked lymphocyte and plasmacyte infiltration, and sometimes fibrosis. A germinal center is frequently observed. IgG4+ plasmacytes are found and satisfy the following criteria: ratio of IgG4+ cells to IgG+ cells of 40% or above, or more than 50 IgG4+ cells/HPF (x400).
- Blood test shows elevated serum IgG4 (≥135 mg/dl).
Definite IgG4-ROD is defined as 1, 2 and 3. Probably IgG4-ROD is defined as 1 and 2. Possible IgG4-ROD is defined as 1 and 3.
Surgical biopsy of the lacrimal gland should be undertaken for histopathologic diagnosis of IgG4-ROD. Malignancy and other benign or infectious processes must be excluded through surgical biopsy and histopathology. If extra-orbital lymph node involvement is present, non-invasive lymph node biopsy may assist in diagnosis as well.
Elevated serum IgG4 levels may be present in IgG4-RD, though 40% of patients with biopsy-proven IgG4-RD will have a normal serum IgG4. The serum IgG4 level tends to be higher in patients with IgG4-ROD, bilateral disease, and in patients with extra-orbital disease. Serum IgG4 levels may be used as a marker for treatment response in patients with IgG4-ROD, as levels were found to significantly decrease in patients after steroid treatment. Patients who experience disease relapse after steroid treatment tend to have increasing serum IgG4 levels with a flare of symptoms. In addition, if serum IgG4 levels remain elevated after steroid treatment, this is predictive of IgG4-ROD relapse.
Other important labs include inflammatory markers such as ESR and CRP, as well as rheumatologic labs that help rule out similar forms of orbital inflammation on the differential. These include, but are not limited to, CBC and LDH (to rule out anemia secondary to lymphoproliferative disease), ANCA serologies (to distinguish IgG4-ROD from granulomatosis with polyangiitis (GPA)), Anti-Ro and Anti-La antibodies (to distinguish IgG4-ROD from Sjogren’s syndrome), ANA, ACE levels (to rule out sarcoidosis), T4, T3, and TSH (to rule out thyroid eye disease). One should also rule out orbital infections with mycobacterial and fungal stains and culture on pathology.
- Granulomatosis with polyangiitis (GPA)
- Sjögren syndrome
- Lymphoma (either primary ocular adnexal lymphoma or systemic lymphoma)
- Orbital infections (dacryoadenitis or orbital cellulitis caused by bacterial or fungal infections)
- Thyroid-related orbitopathy
- Idiopathic orbital inflammation
It is important to obtain tissue diagnosis prior to treatment in order to exclude malignancy. Some patients with IgG4-ROD have been reported to achieve spontaneous remission under observation. However, medical therapy is still considered first-line treatment and surgical resection is not generally employed.
First-line therapy for IgG4-ROD is systemic corticosteroids. Initial response to systemic corticosteroids is excellent, but relapse rates have been reported as high as 70% either during or after treatment. Relapse tends to occur during taper or after cessation of corticosteroid use. Recurrence can be identified by increasing serum IgG4 levels and flare of symptoms related to inflammatory lesions. Patients with lesions that are sclerotic on pathology tend to have less of a response to corticosteroid treatment. While no optimal steroid dose is known for IgG4-ROD, the dose of prednisolone used for IgG4-related pancreatitis is usually 0.6 mg/kg/day with a taper of 5 mg every 1-2 weeks. Some practitioners may maintain patients on a maintenance dose of 5 mg/day of prednisolone, as this was shown to decrease relapse rates from 92% to 23% over a 3-year period.
Management of relapse may involve a 6-10 week course of oral prednisolone or addition of other medications, such as rituximab, due to steroid intolerance or resistance. Rituximab is an anti-CD20+ monoclonal antibody. Suggested cycles of rituximab include two 1-g infusions separated by 14 days. Patients may require more than one cycle of rituximab, or may experience relapse at 6 months when peripheral B-cells are re-populated. Other immunosuppressants such as azathioprine and mycophenolate mofetil have had very limited success.
Medical follow up
Approximately half of patients diagnosed with IgG4-ROD will also have systemic IgG4-RD in other organs. Therefore, arranging follow-up with a rheumatologist for these patients is advised in order to assess involvement of extra-orbital sites. Suggested work-up includes biochemical assessment of liver and renal function, as IgG4-RD may target these organs. CT scan (or MRI) of the head and neck, chest, abdomen, and pelvis is also recommended to exclude mass lesions in these areas. In particular, imaging is highly recommended for patients with bilateral IgG4-ROD, as there is a significant association between bilateral IgG4-ROD and having systemic disease. Whole-body fluorodeoxyglucose (FDG) PET/CT may be used to stage IgG4-RD and to assess response to corticosteroid treatment.
Surgical biopsy of the lacrimal gland, orbital fat, or other involved tissues is employed to obtain a tissue sample for histopathological diagnosis. Surgical resection is typically not necessary unless patients have vision threatening symptoms from mass effect of lesions. There are only four reported cases of surgical resection of IgG4-ROD lesions: one was lost to follow-up, one had clinical improvement after 2 surgical resections, and the remaining two had no improvement post-operatively.
Patients with IgG4-ROD are at increased risk for lymphoma, particularly low-grade extranodal marginal zone B-cell lymphoma of mucosa-associated lymphoid tissue (MALT lymphoma). Untreated IgG4-ROD affecting the lacrimal glands may also lead to irreversible damage and lifelong dry eye disease.
